Introducing the Afridev Indus Hand Pump
Unlocking Water from the Depths
Discover the Afridev Indus Hand Pump, a remarkable public-domain innovation designed to bring water to the surface from depths of 45 to 60 meters below ground. This ingenious pump features a unique “working barrel” mechanism that allows the piston to be easily extracted without the need to remove the rising main.
Unmatched Versatility
The Afridev Hand Pump is tailor-made for various settings, including boreholes with internal diameters of 100 mm, 127 mm, or 200 mm, as well as hand-dug wells. With its specialized hook tool, the foot valve can be effortlessly removed from the cylinder’s base. This hand pump is the ideal solution for boreholes and wells.
Elevate your Water Access Experience
Choose the Afridev Indus Hand Pump, where innovation meets reliability, and water flows effortlessly from the depths. Experience the future of sustainable water solutions.
About our product
Key Features
- Village-Friendly Design: Crafted with Village Level Operation and Maintenance (VLOM) in mind, this pump is easy to maintain, ensuring consistent functionality.
- Deep-Water Champion: Capable of drawing water from depths of approximately 45 meters, the Afridev Hand Pump serves as your reliable water lifeline.
- Durable Steel Structure: The fully fabricated steel structure is meticulously hot-dip galvanised, guaranteeing longevity and resilience.
- Tailored for Depth: With an adjustable handle, the pump adapts effortlessly to various installation depths, ensuring efficiency every time.
- Innovative Bush Bearings: Ingeniously designed injection-moulded plastic bush bearings are easily replaceable at the village level, simplifying maintenance.
- Effortless Extraction: The plunger and foot valves are interchangeable, allowing for quick extraction without the need to remove the riser pipe.
- Corrosion-Resistant: Non-corrosive underground components make this pump ideal for handling corrosive water, significantly extending its lifespan.
- Ease of Installation: Designed for straightforward installation and cost-effective maintenance at the village level, it is user-friendly for everyone, including women.
Riser Pipe
- Connection: Connects the cylinder to the pump head, facilitating the passage of water.
- Durable Design: Sturdy uPVC pipe with a rubber pipe centraliser to prevent contact with the casing pipe.
- Specifications: Measures 63 mm OD x 4.7 mm wall thickness x 2.9 meters in length.
Pump Head Assembly
- Robust Structure: Hot-dip galvanised steel construction ensures durability and resistance to corrosion.
- Adjustable Handle: Designed to accommodate various cylinder settings for flexibility.
- Secure Flange: Conical flange with rubber grommet provides a secure hold on the UPVC riser pipe.
- Easy Replacement: Plastic bush bearings for the fulcrum and rod hanger pins allow for straightforward replacement.
- Covered Design: Protects water quality by minimising contamination risks.
- Efficient Stroke Length: Offers a comfortable 225 mm stroke length for effective pumping.
Cylinder Assembly Details
- Durable Construction: Lined uPVC pipe with a seamless brass liner for enhanced durability.
- Interchangeable Components: Plunger and foot valves crafted from innovative materials for easy replacement.
- Hassle-Free Extraction: Foot valve equipped with a pick-up device for easy extraction without removing the riser pipe.
- Optimal Performance: Features high-quality seals, bobbins, and O-rings for reliable operation.
- Reduced Intake: Larger diameter extension pipe minimises silt and sand intake.
- Installation Support: Sleeve provided for rope support during installation and maintenance.
